ELECTRICAL CIRCUIT DIAGRAM
7-2
ELEC
B Black B/Y Black/Yellow
Br Brown Br/B Brown/Black
Ch Chocolate Br/W Brown/White
Dg Deep green G/B Green/Black
G Green G/R Green/Red
Gy Grey G/W Green/White
L Blue G/Y Green/Yellow
Or Orange L/R Blue/Red
P Pink L/W Blue/White
R Red L/Y Blue/Yellow
Sb Sky-blue R/B Red/Black
W White R/W Red/White
Y Yellow R/Y Red/Yellow
B/R Black/Red W/L White/Blue
B/W Black/White Y/R Yellow/Red
(1) AC generator/Pickup coil
(2) Rectifier/Regulator
(3) Battery
(4) Starter relay
(5) Starting motor
(6) Fuse
(7) Main switch
(8) Right handlebar switch
(9) Engine stop switch
(10) Starter switch
(11) Diode
(12) Clutch switch
(13) Sidestand switch
(14) Neutral switch
(15) Diode
(16) Ignitor unit
COLOUR CODE
(17) Ignition coil
(18) Left handlebar switch
(19) Horn switch
(20) Diode
(21) Pass switch
(22) Dimmer switch
(23) Flasher switch
(24) Horn
(25) Flasher relay
(26) Headlight
(27) Flasher light
(28) Relay assy
(29) Front brake switch
(30) Rear brake switch
(31) Tail/stop light
(32) Meter
