ILLUSTRATED SYMBOLS
The following symbols are not relevant to every
vehicle.
Illustrated symbols 1 to 8 are printed on the top
right of each page and indicate the subject of
each chapter.
1 General information
2 Specifications
3 Periodic inspections and adjustments
4 Chassis
5 Engine
6 Carburetor
7 Electrical system
8 Troubleshooting
Illustrated symbols 9 to y are used to identify
the specifications appearing in the text.
9 Can be serviced with engine mounted
0 Filling fluid
q Lubricant
w Special tool
e Torque
r Wear limit, clearance
t Engine speed
y Electrical data
Illustrated symbols u to s in the exploded dia-
grams indicate the types of lubricants and lubrica-
tion points.
u Apply engine oil
i Apply gear oil
o Apply molybdenum disulfide oil
p Apply wheel bearing grease
a Apply lightweight lithium-soap base grease
s Apply molybdenum disulfide grease
Illustrated symbols d to f in the exploded dia-
grams indicate the following:
d Apply locking agent (LOCTITE
®
)
f Replace the part
GEN
INFO
SPEC
INSP
ADJ
CHAS
ENG CARB
ELEC
TRBL
SHTG
New
12
34
?
56
78
90
qw
er
ty
uoi
psa
df
