CHAS
FRONT FORK
4-45
OIL CAPACITY (IN EACH FORK LEG): 650 cm
3
RECOMMENDED OIL:
Liqui Moly Racing suspension oil SAE 7,5
FRONT FORK OIL LEVEL
STANDARD 180 mm
MINIMUM 190 mm
MAXIMUM 170 mm
From top of inner tube with inner tube fully com-
pressed without spring.
MINIMUM FORK SPRING FREE LENGTH:
530 mm
INNER TUBE BENDING LIMIT:
0.2 mm
1. Park the motorcycle on a level surface.
2. Raise the front wheel by placing a suitable
support under the engine.
3. Remove:
•
Front wheel
Refer to “FRONT WHEEL REMOVAL”
section.
4. Remove:
•
Inner tube protector
•
Protector guide
•
Gear unit assembly and cable
•
Brake caliper and hose
5. Loosen:
•
Cap bolt
•
Pinch bolt (upper and lower bracket)
WARNING
Securely support the motorcycle so there is
no danger of it falling over.
FRONT FORK REMOVAL
