Canon imagePROGRAF iPF830 User Manual

7
Click the Page Setup tab to display the Page Setup
sheet.
8 In the A Page Size list, click the size of the original as specified in the application. In this case, click ISO
A4 or Letter (8.5"x11").
9 In H Orientation, click J Landscape.
10 Select and click a roll paper in the L Paper Source list.
11 Select the width of the loaded roll in the M Roll Paper Width list—in this case, ISO A2/A3 Roll
(420.0mm).
12 Confirm the print settings and print as desired.
Note
•
For tips on confirming print settings, see "Confirming Print Settings ." ➔P.149
Making the Original Orientation Match the Paper Orientation (Mac OS)
Making the Original Orientation Match the Paper Orientation (Mac OS)
This topic describes how to print an original in landscape orientation after matching the paper orientation, based on
the following example.
• Document: An original in landscape orientation
• Page size: A4 (210.0 × 297.0 mm [8.3 × 11.7 in])
• Paper: Roll paper
• Paper type: Plain Paper
• Roll paper width: A2/A3 roll (420.0 mm [16.5 in])
1
Choose Page Setup from the application menu to
display the Page Attributes dialog box.
Making the Original Orientation Match the Paper Orientation (Mac OS) iPF830
User's Guide
Enhanced Printing Options Other useful settings
138

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
