Portrait Orientation/Landscape Orientation(Word)
Portrait Orientation/Landscape Orientation(Word)
Print to the edge of the roll width. You can print large exhibits and posters, or print the Landscape or Portrait Orien-
tation Page Sizes made in the Large-Format Printing Wizard.
Create Page Size in Portrait or Landscape Orientation.
Use the Large-Format Printing Wizard to create portrait page sizes for Potrait Orientation, and landscape page
sizes for Landscape Orientation.
1 Start Microsoft Word.
2
If Start imagePROGRAF Print Plug-In is displayed, click it.
3 Click Paper Settings from the imagePROGRAF Print Plug-In toolbar/ribbon.
The Large-Format Printing Wizard dialog box is displayed.
Note
•
If you want to change the display to another file or application while the Large-Format Printing Wizard is
open, close the Large-Format Printing Wizard dialog box. Otherwise, you may not be able to change
displays or operate the toolbar/ribbon.
4 Click Portrait Orientation or Landscape Orientation.
Note
•
The steps taken to create a Portrait Page Size will be used as an example to explain the procedure.
iPF830 Portrait Orientation/Landscape Orientation(Word)
User's Guide
Windows Software Print Plug-In for Office
233

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
