Note
• You can input between 10 and 400.
• You can change the numbers by clicking ▼ button.
Go to Page Dialog Box
Go to Page Dialog Box
This dialog box appears when you select Go to Page from the View menu.
Note
•
You can not select Go to Page if the document is only one page.
•
Page
Input the page number in numerical characters to display in the preview area.
Note
•
You can change the numbers in the range of the page of the documents.
Print with No Borders
Print with No Borders
You can use the borderless printing function to print without margins surrounding the image.
Note
•
With some media borderless printing can be performed only between two edges.
• To use the borderless printing function, the specified media must be set to the printer.
1 On the Paper Settings Panel ➔ P.278 , select Roll Paper in Paper Source.
2 On the Output Settings Panel ➔ P.281 , click the Enlarged/Reduced Printing check box on.
3 Select Fit Roll Paper Width.
4
Click the Borderless Printing check box on.
5 Click the Print button.
Borderless printing begins.
Go to Page Dialog Box iPF830
User's Guide
Mac OS Software Preview
290

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
