Cause Corrective Action
You are printing on heavyweight paper
or paper that curls or wrinkles easily af-
ter absorbing ink.
For paper-based media such as Heavyweight Coated Paper, set the VacuumStrngth to
Strong or Strongest in the Control Panel menu. If the paper still rubs against the print-
head, set the Head Height in the Control Panel menu to a higher value than the current
setting.
(See "Adjusting the Vacuum Strength.") ➔ P.564
(See "Troubleshooting Paper Abrasion and Blurry Images.") ➔ P.556
For film-based media such as Tracing Paper, set the VacuumStrngth to Standard,
Strong or Strongest in the Control Panel menu. If the paper still rubs against the print-
head, set the Head Height in the Control Panel menu to a higher value than the current
setting.
(See "Adjusting the Vacuum Strength.") ➔ P.564
(See "Troubleshooting Paper Abrasion and Blurry Images.") ➔ P.556
The Ejection Guide is soiled. Clean the Ejection Guide.
(See "Cleaning the Printer Exterior.") ➔P.591
The surface of the paper is dirty
The surface of the paper is dirty
Cause Corrective Action
The Paper Retainer is soiled. Clean the Paper Retainer.
(See "Cleaning Inside the Top Cover.") ➔ P.591
You are using a paper that does
not dry easily.
In the Control Panel menu, set Roll DryingTime to at least 1 min.
(See "Menu Settings.") ➔P.442
When paper that does not dry easily is used for printing, it may curl during printing and touch the
Output Tray.
In this case, in the Control Panel menu, complete the settings for Dry time and Area in Scan
Wait Time.
However, note that printing will now take longer.
(See "Menu Settings.") ➔P.442
The back side of the paper is dirty
The back side of the paper is dirty
Cause Corrective Action
The Platen has become dirty after borderless
printing or printing on small paper.
Open the Top Cover and clean the Platen.
(See "Cleaning Inside the Top Cover.") ➔ P.591
In the Control Panel menu, set CarriageScanWdth to Fixed.
(See "Menu Settings.") ➔P.442
The Platen has become soiled because you have
set Width Detection to Off in the Control Panel
menu.
Set Width Detection to On in the Control Panel menu, and then open the Top
Cover and clean the Platen.
(See "Cleaning Inside the Top Cover.") ➔ P.591
Open the Top Cover and clean the Platen. After this, manually advance the roll
onto the Platen before printing.
(See "Cleaning Inside the Top Cover.") ➔ P.591
(See "Feeding Roll Paper Manually.") ➔P.341
The Platen suction is too strong. In the Control Panel menu, reduce the level of VacuumStrngth.
(See "Adjusting the Vacuum Strength.") ➔ P.564
Printed colors are inaccurate
Printed colors are inaccurate
Cause Corrective Action
Color adjustment has not been activated in the Ad-
vanced Settings of the printer driver.
In the Advanced Settings of the printer driver, access Color Settings in Col-
or Mode to adjust colors.
(See "Main Sheet (Windows).") ➔P.154
(See "Main Pane (Mac OS).") ➔P.260
Colors have not been adjusted on the computer or
monitor.
Refer to the computer and monitor documentation to adjust the colors.
Adjust the settings of the color management software, referring to the software
documentation as needed.
The Printhead nozzles are clogged. Print a test pattern to check the nozzles and see if they are clogged.
iPF830
The surface of the paper is dirty
User's Guide
Troubleshooting Problems with the printing quality
621

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
