Canon imagePROGRAF iPF830 User Manual

2
Place the pointer at a corner of the selection box
around the object to show the arrow handle, and drag
this handle to change the object size.
Resizing by specifying a scaling value
1 Select an object.
Click on the Enl./Red. checkbox in the Format Dialog Box ➔ P.192 and select Scaling.
2 You either enter numbers directly.
Note
•
You can input between 25 and 600.
• You can change the numbers by clicking either ▲ button or ▼ button.
3 Click the OK button.
Moving an Object
Moving an Object
You can move the object position.
1 Select an object.
2
Place the pointer inside the selection box of the ob-
ject to show the crosshair handle, and drag it to move
the object.
Alternatively, you can move the Object Position by
changing the values in Vertical Pos, Horizontal Pos
and Page Pos in the Format Dialog Box ➔ P.192 .
Rotating an Object
Rotating an Object
You can rotate the object.
1 Select an object.
iPF830 Moving an Object
User's Guide
Windows Software Free Layout
199

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
