Canon imagePROGRAF iPF830 User Manual

Printer Menu
Printer Menu
Printer Menu Operations ................................................................................................................................. 431
Menu Operations ............................................................................................................................................ 432
Menu Structure .............................................................................................................................................. 435
Menu Settings ................................................................................................................................................ 442
Status Print .................................................................................................................................................... 453
Printing Interface Setting Reports ................................................................................................................... 456
Setting Control panel access lock ................................................................................................................... 458
Printer Menu Operations
Printer Menu Operations
The printer menu is classified into regular menu items available when no print job is in progress and menu during
printing items only available while printing is in progress.
• Regular menu operations ➔ P.431
• Menu operations during printing ➔ P.431
Regular menu operations
To view available menus organized on tabs, select a tab on the Tab Selection screen and press the OK button.
Note
•
If the Tab Selection screen is not displayed, pressing OK will not display menus.
Menus can be selected after you resolve the problem.
• If the Control panel access lock is set, pressing OK button will not display menus.Contact the printer administra-
tor.
(See "Setting Control panel access lock.") ➔P.458
The following operations are available from the menu.
• Paper Menu
Paper menu settings
• Ink Menu
Ink menu operations
• Job Menu
Menu operations to manage print jobs
• Set./Adj. Menu
Menu operations for printer adjustment and maintenance
For a description of specific menu items available, see "Menu Settings." ➔ P.442
For instructions on selecting menu items, see "Menu Operations." ➔ P.432
Note
•
By default, menu settings apply to all print jobs. However, for settings that are also available in the printer driver,
the values specified in the printer driver take priority.
Menu operations during printing
During printing, only a limited set of menu items are displayed. Menu items that are not displayed during printing
should be operated after printing has finished.
To display menus during printing, select a tab on the Tab Selection screen on the Control Panel, and then press
the OK button.
Note
•
If the Tab Selection screen is not displayed, pressing OK will not display menus.
Menus can be selected after you resolve the problem.
• If the Control panel access lock is set, pressing OK button will not display menus.Contact the printer administra-
tor.
(See "Setting Control panel access lock.") ➔P.458
iPF830 Printer Menu Operations
User's Guide
Control Panel Printer Menu
431

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
