Canon imagePROGRAF iPF830 User Manual

Messages regarding printing or adjustment
Messages regarding printing or adjustment
Cannot print as specified. ............................................................................................................................... 651
Cannot adjust printhead. ................................................................................................................................ 652
Borderless printng not possible. Paper stretched or shrank. ........................................................................... 651
Before borderless printing, move the blue platen switch. ................................................................................ 651
Borderless printng not possible. ..................................................................................................................... 647
Blue platen switch is dirty. .............................................................................................................................. 651
Move the blue platen switch No.xx to the right. (xx represents a number) ....................................................... 651
Check printed document. ............................................................................................................................... 651
Cannot print as specified.
Cannot print as specified.
"Lift the release lever and replace paper with A4/LTR (vertical) or larger."
Cause Corrective Action
The loaded paper is too small. Switch to paper A4/Letter (vertical) or larger.
"Lift the release lever and replace roll with 10 in. wide or larger roll."
Cause Corrective Action
The loaded paper is too small. Load a roll 10 inches wide or larger.
Borderless printng not possible. Paper stretched or shrank.
Borderless printng not possible. Paper stretched or shrank.
Cause Corrective Action
The loaded roll has expanded or contracted due to environmen-
tal conditions, making it wider or narrower than the supported
width for borderless printing.
Press the OK button to stop printing.
Use each type of paper only where the recommended environ-
mental conditions are met. For details on environmental condi-
tions for various paper, see the Paper Reference Guide.
(See "Displaying the Paper Reference Guide.") ➔P.323
Before borderless printing, move the blue platen switch.
Before borderless printing, move the blue platen switch.
Cause Corrective Action
The blue Switch on the platen was set to the side oppo-
site ● when a borderless print job was received.
Before borderless printing, set the blue Switch on the platen to the ● side.
(See "Setting the Blue Switch on the Platen.") ➔P.623
Blue platen switch is dirty.
Blue platen switch is dirty.
Cause Corrective Action
The blue Switch on the platen is dirty. Open the Top Cover and clean the blue Switch on the platen.
(See "Cleaning Inside the Top Cover.") ➔ P.591
Move the blue platen switch No.xx to the right. (xx represents a number)
Move the blue platen switch No.xx to the right. (xx represents a number)
Cause Corrective Action
The printer has detected that the blue Switch on the platen nee-
ded in maintenance during printing is set away from the ● mark.
Set blue platen Switch of the indicated number toward the ● side.
(See "Setting the Blue Switch on the Platen.") ➔P.623
Check printed document.
Check printed document.
Cause Corrective Action
The Printhead nozzles are becoming clogged. If printing is faint, clean the Printhead.
(See "Cleaning the Printhead.") ➔P.578
iPF830
Cannot print as specified.
User's Guide
Error Message Messages regarding printing or adjustment
651

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
