Canon imagePROGRAF iPF830 User Manual

Paper jam.
Paper jam.
"Lift the release lever."
Cause Corrective Action
A paper jam occurred
in the printer during
printing.
1. Lift the Release Lever and remove the jammed paper.
(See "Clearing Jammed Roll Paper.") ➔P.607
(See "Clearing a Jammed Sheet.") ➔P.610
2. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press the
OK button.
Printing will resume, starting from the page on which the error occurred.
"Manually rewind the roll all the way and press OK."
Cause Corrective Action
A paper jam occurred
when advancing the pa-
per.
1.
Rewind paper on the Roll Holder manually, all the way, and then press the OK button.
2. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press
the OK button.
Printing will resume, starting from the page on which the error occurred.
"Lift the release lever and remove the paper."
Cause Corrective Action
A paper jam occurred in the printer during printing. Lift the Release Lever and remove the jammed paper.
(See "Clearing Jammed Roll Paper.") ➔P.607
(See "Clearing a Jammed Sheet.") ➔P.610
Paper loaded askew.
Paper loaded askew.
Cause Corrective Action
Paper loaded crooked was detected when the paper was advanced. Lift up the Release Lever and reload the
paper.
(See "Loading Rolls in the Print-
er.") ➔P.333
(See "Loading Sheets in the Print-
er.") ➔P.353
If this error recurs after you reload the roll,
remove the Roll Holder from the printer,
push the roll firmly in until it touches the
Roll Holder flange, and reload the Roll
Holder in the printer.
(See "Attaching the Roll Holder to
Rolls.") ➔P.330
Important
•
To disable this message (if it is displayed repeatedly despite reloading paper, for example), choose Off or Loose
in the Skew Check Lv. setting of the printer menu. However, this may cause jams and printing problems because
paper may be askew when printed. Also, the Platen may become soiled, which may soil the back of the next
document when it is printed.
Paper cutting failed.
Paper cutting failed.
Cause Corrective Action
There are sheets left on the
Ejection Guide.
1.
Lift the Release Lever and remove the paper.
2. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen,
press the OK button.
Printing will resume, starting from the page on which the error occurred.
iPF830 Paper jam.
User's Guide
Error Message Messages regarding paper
645

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
