Preview
Preview
The Features of Preview ................................................................................................................................. 176
Starting Preview ............................................................................................................................................. 176
Preview Main Window .................................................................................................................................... 177
Dialog Area ..................................................................................................................................................... 179
Enlarge/Reduce the screen display ................................................................................................................. 180
Moving a Page ............................................................................................................................................... 180
Using the ruler ................................................................................................................................................ 180
Priority setting for rotating 90 degrees ............................................................................................................ 181
Printing with Selecting the Layout ................................................................................................................... 182
Print on the Center ......................................................................................................................................... 184
Not Print Spaces at the Top/Bottom ............................................................................................................... 185
The Features of Preview
The Features of Preview
The main features of Preview are as follows.
• While viewing this screen, you can adjust layout settings of a document created with application software.
• You can not only adjust layout settings but also your changes will be instantly applied on the preview screen,
and you can print the preview screen as it is seen.
Note
•
The media type, image size, detailed media settings, and the printer settings can cause the actual print output to
differ from the Preview settings.
Starting Preview
Starting Preview
Follow the procedure below to start the Preview.
1 Start the apllication software which you use.
2 From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
•
Normally, select Print from the File menu.
3
On the Main sheet, click on the Open Preview When
Print Job Starts check box.
Click the OK button to save the settings.
Note
•
Your printer is depicted in the lower-left area of this screen.
The Features of Preview iPF830
User's Guide
Windows Software Preview
176

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
