Canon imagePROGRAF iPF830 User Manual

2
Select Rotate Left 90 Degrees orRotate Right 90
Degrees from the toolbar.
Alternatively, you may click on the Rotate check box
in the Format Dialog Box ➔ P.192 then select Rotate
Right or Rotate Left, and click the OK button.
Laying out Objects Automatically
Laying out Objects Automatically
Click Auto Arrange Object in the tool bar. This automatically lays out objects. Alternatively, you may select Auto
Arrange Object from the Object menu.
Note
•
The object layout order varies depending on the Order setting in the Page Options Dialog Box ➔ P.191 dialog box.
Aligning Objects
Aligning Objects
You can align objects systematically.
1 Select multiple objects.
2 Click the align button from the toolbar.
Alternatively, you may select the align menu from the Object menu.
•
Align Top
Lays out the objects, justifying them to the top.
Laying out Objects Automatically iPF830
User's Guide
Windows Software Free Layout
200

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
