Messages regarding printheads
Messages regarding printheads
Cannot adjust printhead. ................................................................................................................................ 652
Wrong printhead. ............................................................................................................................................ 652
Printhead error ............................................................................................................................................... 652
Cannot recognize print head. ..........................................................................................................................652
Execute printhead cleaning. ............................................................................................................................ 653
Cannot adjust printhead.
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are
clogged.
Execute Head Posi. Adj. again, as follows.
1. Press the OK button to clear the error.
2. Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.") ➔P.577
3. Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.") ➔P.578
4. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors.") ➔P.550
The Printhead cannot be
aligned; highly transparent film
is loaded.
Press the OK button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjustment.
(See "Automatic Adjustment to Straighten Lines and Colors.") ➔P.550
The Printhead is installed
crooked.
Straighten the Printhead as follows, and then execute Head Posi. Adj. again.
1. Press the OK button to clear the error.
2. Use Head Inc. Adj. to adjust the angle of inclination of the Printhead.
(See "Adjusting Line Misalignment.") ➔P.554
3. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors.") ➔P.550
Wrong printhead.
Wrong printhead.
Cause Corrective Action
An incompatible Printhead has been installed. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.") ➔P.579
Printhead error
Printhead error
Cause Corrective Action
There is a problem with the Printhead. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.") ➔P.579
Cannot recognize print head.
Cannot recognize print head.
Cause Corrective Action
No Printhead is installed. Follow these steps to install the Printhead.
1.
Open the Top Cover.
2. Install the Printhead.
(See "Replacing the Printhead.") ➔P.579
The Printhead cannot be recognized because it is not installed correctly. Follow these steps to reinstall the Printhead.
1. Open the Top Cover.
2. Reinstall the Printhead.
(See "Replacing the Printhead.") ➔P.579
Cannot adjust printhead. iPF830
User's Guide
Error Message Messages regarding printheads
652

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
