Canon imagePROGRAF iPF830 User Manual

Applying a Saved Media Information File on Another Computer
Applying a Saved Media Information File on Another Computer
You can import and use the media information file you saved from your computer on other printers and computer by
using the following procedure.
Important
• Do not attempt to print or turn the printer off while the program is communicating with the printer.
1 Copy the saved media information file (.amx) onto the other computer.
2 Install and run the Media Configuration Tool on the other computer.
3 Select the printer in the Select Printer dialog box, and then click the Next button.
Note
•
Select the printer model that matches the media information file you are attempting to import.
4
Select Specify the Media Information File in the
Add Media Type dialog box, click the Browse but-
ton, and then specify the folder that contains the .amx
file you copied.
Select the check box for the media information file
name and click the OK button.
Note
•
If the Media Configuration Tool main window is displayed at this time, click the Add Genuine Paper but-
ton, and then click the Add button on the screen that opens.
5
The Media Configuration Tool main window is dis-
played. Click the Add Genuine Paper button.
Note
•
If the Edit Media Types dialog box is displayed without the main window appearing, proceed to the fol-
lowing step.
iPF830 Applying a Saved Media Information File on Another Computer
User's Guide
Handling and Use of Paper Media Configuration Tool (Windows)
395

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
