8 Edit and create the document.
Important
• The layout may collapse if you create a form using existing data. If that is the case, modify the data
again.
Note
• Printing is done in Print Matching Roll Width of the Printing Wizard. For details on Print Matching Roll
Width, see "Print Matching Roll Width(PowerPoint)." ➔P.236
To start from Microsoft Excel
To start from Microsoft Excel
Below are the steps to start Print Plug-In for Office from Microsoft Excel.
1 Start Microsoft Excel.
2
If Start imagePROGRAF Print Plug-In is displayed on the toolbar/
ribbon, click it.
Important
•
If the imagePROGRAF Print Plug-In toolbar/ribbon is not displayed, refer to the following.
• When Print Plug-In for Office is not displayed ➔P.220
3
Check that the imagePROGRAF Print Plug-In toolbar/ribbon
is displayed.
4 Click the buttons on the toolbar/ribbon according to the items you want to set.
Icon Contents
Menu
Displays the About, Help, and Special Settings dialog boxes. (See "Configuring Spe-
cial Settings.") ➔P.252
Printer list
Select Printer.
If you select Show All Printers, the imagePROGRAF printers will be displayed again.
Select this when you want to display all printer drivers or update the display.
PrintButton
The print Wizard is displayed.
The settings Print Entire Sheet and Print Selected Area can be set.
iPF830 To start from Microsoft Excel
User's Guide
Windows Software Print Plug-In for Office
245

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
