Note
• To display the Paper Information on Printer dialog box, on the Main sheet, click Get Information by Media Type.
(See "Main Sheet .") ➔P.154
•
A Paper Source
Shows the paper source supported by the printer, as well as information about the loaded paper. To update the
paper source and media type settings in the printer driver, select the desired Paper Source option and click
OK.
Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box
In the Paper Detailed Settings dialog box, you can set Drying Time for the paper selected with Media Type of the
Main sheet, etc.
You can display this dialog box by clicking Advanced Settings of Media Type on the Main sheet. (See "Main
Sheet .") ➔ P.154
As for the items for which you can select Printer Default in this dialog box, you also can set them from the control
panel of the printer. (See "Menu Settings.") ➔P.442
A Drying Time
Specify the time that the printer waits for ink to dry, as needed. The Between Pages setting is only valid for rolls.
• B Between Pages
You can set the time to wait after printing 1 document page until ejecting the paper. Since waiting time is re-
quired for ink to dry before a roll is cut, you can deliver paper in the Output Stacker with the ink dried even if
Cutting Mode is set to Automatic.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
Off Paper is ejected immediately after printing completes.
30 sec. / 1 min. / 3 min. / 5 min. /
10 min. / 30 min. / 60 min.
Paper is ejected when the set time elapses after printing completes.
• C
Between Scans
You can set the time to wait after printing 1 line on a page until printing the next line. Set this to avoid bleeding
or color unevenness such as when bleeding occurs on a page or when color unevenness occurs during bor-
derless printing.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
Off The next line is printed immediately after a line is printed.
1 sec. / 3 sec. / 5 sec. / 7 sec. / 9
sec.
The next line is printed when the set time elapses after a line is printed.
* Increase the time according to the occurrence condition of bleeding or unevenness.
Paper Detailed Settings Dialog Box iPF830
User's Guide
Windows Software Printer Driver
158

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
