Canon imagePROGRAF iPF830 User Manual

8
In the Edit Media Types dialog box, click the Update
button.
9
The Confirm Update dialog box is displayed.
Configure Update Target and click the Execute but-
ton.
The printer control panel and printer driver media in-
formation is updated.
Note
•
You should normally select Update the printer control panel and printer driver.
10
The message on the right is displayed.
If you want to save the current media information in a file,
click the Yes button. If you do not want to save it, click the
No button.
Note
•
The media information is saved as a media information file (.amx file).
• For the method for loading a saved media information file in another computer, see "Applying a Saved
Media Information File on Another Computer." ➔P.418
Media Configuration Tool Main Window
Media Configuration Tool Main Window
The explanation below is on the Media Configuration Tool main window.
Use the following procedure to open Media Configuration Tool main window.
Important
•
Do not attempt to print or turn the printer off while the program is communicating with the printer.
1 From the Applications menu, select Canon Utilities > imagePROGRAF Media Configuration Tool >
CNWIMCT.
iPF830 Media Configuration Tool Main Window
User's Guide
Handling and Use of Paper Media Configuration Tool (Mac OS)
403

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
