Setting Details
Crop Marks You can print with the crop marks.
Page Options Dialog Box
Page Options Dialog Box
This dialog box appears when you select Page Options from the File menu. This allows you to configure the roll
paper length, object layout order, and margins of Free Layout.
•
Roll Paper Length
Set the length of one page to print on roll paper.
The following settings are available for roll paper length.
Setting Details
Auto Settings The one-page length to be printed on roll paper is automatically set so that the laid-out
objects are printed on one page.
Manual Settings You can input the length of one page to print on roll paper in numerical characters.
Note
•
Available only if rolls are selected in Paper Source.
• You can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Order
Set the object layout order.
The following settings are available for order.
Setting Details
Upper Left to Right The objects are laid out from upper left to right.
Upper Left to Bottom The objects are laid out from upper left to bottom.
Upper Right to Left The objects are laid out from upper right to left.
Lower Left to Top The objects are laid out from lower left to top.
Note
•
When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Vertical, you can
choose Upper Left to Right or Upper Right to Left.
• When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Horizontal, you can
choose Upper Left to Bottom or Lower Left to Top.
iPF830 Page Options Dialog Box
User's Guide
Windows Software Free Layout
191

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
