Canon imagePROGRAF iPF830 User Manual

Problems with the printing quality
Problems with the printing quality
Printing is faint ................................................................................................................................................ 619
Paper rubs against the Printhead .................................................................................................................... 620
The edges of the paper are dirty ..................................................................................................................... 620
The surface of the paper is dirty ..................................................................................................................... 621
The back side of the paper is dirty .................................................................................................................. 621
Printed colors are inaccurate .......................................................................................................................... 621
Banding in different colors occurs ................................................................................................................... 622
Colors in printed images are uneven ............................................................................................................... 622
Image edges are blurred or white banding occurs .......................................................................................... 623
Setting the Blue Switch on the Platen ........................................................................................................ 623
The contrast becomes uneven during printing ................................................................................................ 626
The length of printed images is inaccurate in the feeding direction .................................................................. 626
Images are printed crooked ............................................................................................................................ 626
Documents are printed in monochrome .......................................................................................................... 626
Line thickness is not uniform .......................................................................................................................... 627
Lines are misaligned ....................................................................................................................................... 627
Printing is faint
Printing is faint
Cause Corrective Action
You may be printing on the
wrong side of the paper.
Print on the printing surface.
The Printhead nozzles are clog-
ged.
Print a test pattern to check the nozzles and see if they are clogged.
(See "Checking for Nozzle Clogging.") ➔P.577
To check for nozzles after printing, set Frequency in Nozzle Check in the Control Panel menu to
a setting other than Off.
Furthermore, to have a warning displayed depending on the result of the nozzle check, set
Warning in Nozzle Check in the Control Panel menu to On.
Note that when Warning is set to On, printing may stop depending on the content of the warn-
ing.
(See "Menu Settings.") ➔P.442
Because the printer was left
without ink tanks installed for
some time, ink has become
clogged in the ink supply sys-
tem.
After the ink tanks have been installed for 24 hours, run Head Cleaning B from the Control Pan-
el.
(See "Cleaning the Printhead.") ➔P.578
Paper is jammed inside the Top
Cover.
Follow the steps below to remove the jammed piece of paper inside the Top Cover.
1.
Open the Top Cover and make sure the Carriage is not over the Platen.
2. Remove any scraps of paper inside the Top Cover.
(See "Clearing Jammed Roll Paper.") ➔P.607
(See "Clearing a Jammed Sheet.") ➔P.610
3. Close the Top Cover.
The ink was not dry when paper
was cut.
Specify a longer drying period in the Control Panel menu, in Paper Details > Roll DryingTime.
(See "Menu Settings.") ➔P.442
Printing may be faint if Print
Quality in Advanced Settings
in the printer driver is set to
Standard or Fast.
In Advanced Settings of the printer driver, choose Highest or High in Print Quality.
Printing in Fast or Standard mode is faster and consumes less ink than in Highest or High
modes, but the printing quality is lower.
(See "Giving Priority to Particular Graphic Elements and Colors for Printing.") ➔P.54
You are printing on paper that
tends to generate dust when cut.
In the Control Panel menu, set CutDustReduct. in Paper Details to On.
(See "Reducing Dust from Cutting Rolls.") ➔P.351
iPF830 Printing is faint
User's Guide
Troubleshooting Problems with the printing quality
619

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
