2 Press the OK button.
The Set./Adj. Menu is displayed.
3 Press ▲ or ▼ to select Interface Setup, and then press the OK button.
4 Press ▲ or ▼ to select TCP/IP, and then press the OK button.
5 Press ▲ or ▼ to select IPv4, and then press the OK button.
6 Press ▲ or ▼ to select IPv4 Settings, and then press the OK button.
7 Press ▲ or ▼ to select IP Address, and then press the OK button.
8 After you press ◀ or ▶ to select the input field, numerical input is possible.
9 Press the ▲ or ▼ button to enter the value.
Note
•
Pressing the ▲ button increases the number by 1. The maximum value is 9, after which 0 is displayed.
• Pressing the ▼ button decreases the number by 1. The minimum value is 0, after which 9 is displayed.
• Hold down ▲ or ▼ to increase or decrease the value continuously.
• Make sure the IP address you enter for the printer is not the same as any computer IP address in your
network.
10 Repeat steps 8 and 9 to complete the settings, and then press the OK button.
11
Press the Menu button.
If you have changed the settings, a confirmation message
is displayed. Press ▲ or ▼ to select Yes, and then press
the OK button.
Important
•
Be sure to complete step 11. This will activate the values you have entered.
• If an error message is displayed, check the settings and correct any invalid values.
Note
• You can also specify the subnet mask and default gateway on the Control Panel.
Configuring the IP Address Using ARP and PING Commands
Configuring the IP Address Using ARP and PING Commands
This topic describes how to configure the IP address using ARP and PING commands.
To use the ARP and PING commands, you will need to know the printer's MAC address. You can confirm the MAC
address on the Control Panel.
1 Check the printer's MAC address.
You can confirm the MAC address on the Control Panel as follows:
1.
On the Tab Selection screen of the Control Panel, press ◀ or
▶ to select the Settings/Adj. tab (
).
iPF830 Configuring the IP Address Using ARP and PING Commands
User's Guide
Network Setting Initial Settings
481

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
