Setting Details
Specify Folded Size Prints by automatically enlarging or reducing the entire document to match the size of the
paper. Select the actual size of the paper you want to print on in Fit Paper Size.
Rotate Page 90 degrees (Con-
serve Paper)
Prints by rotating pages by 90 degrees. Pages are automatically rotated if they will fit with-
in the roll paper width when rotated, and are not rotated if they will not fit within the roll
paper width.
Binding Settings Dialog Box
Binding Settings Dialog Box
This is displayed when you select Binding Settings from theEdit menu. This allows you to configure the binding
edge settings.
•
Binding Edge
Configures the binding edge when folding paper.
The following settings are available for the binding edge.
Setting Details
Bottom Prints by placing the binding margin (gutter) at the bottom of the document.
Top Prints by placing the binding margin (gutter) at the top of the document.
• Binding
Configures the binding margin (gutter).
Prints by creating a binding margin (gutter) of the specified size. Enter the margin size as a number.
Note
•
The values that can be entered are 0 to 50 (mm).
•
Print Fold Lines
Configures the color and type of fold lines.
Note
•
To not print fold lines, clear the Print Fold Lines checkbox.
•
Fold Line Color
You can select the fold lines.
• Fold Line Type
You can select the fold lines.
The following settings are available for the fold line type.
Setting Details
Solid Line You can print the solid line as the frame style.
Dotted Line You can print the dotted line as the frame style.
Dashed Line You can print the dashed line as the frame style.
Binding Settings Dialog Box
iPF830
User's Guide
Windows Software Free Layout
206

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
