Canon imagePROGRAF iPF830 User Manual

• If you switch to printing in a TCP/IP network, or if the printer's IP address is changed, see "Configuring the
Destination in TCP/IP Networks ." ➔ P.487
• If you switch to printing in a Bonjour network, see "Configuring the Destination for Bonjour Network ." ➔ P.487
Configuring the Printer's TCP/IP Network Settings With RemoteUI
Configuring the Printer's TCP/IP Network Settings With RemoteUI
Follow the steps below to configure the TCP/IP network settings.
When using an IPv4 IP address
1 Start the web browser and enter the following URL in the Location (or Address ) box to display the Remo-
teUI page.
http://printer IP address or name/
Example: http://xxx.xxx.xxx.xxx/
2 Select Administrator Mode and click Logon.
Note
•
If a password has been set on the printer, enter the password.
3 Click Network in the Device Manager menu at left to display the Network page.
4 Click Edit in the upper-right corner of the TCP/IPv4 group to display the Edit TCP/IP Protocol Settings
page.
5 Refer to the TCP/IP Settings Items table to complete the settings.
TCP/IP Settings Items
Item Details Default Setting
Use DHCP Activate this setting to use DHCP for configuring the IP address. Off
Use BOOTP Activate this setting to use BOOTP for configuring the IP address. Off
Use RARP Activate this setting to use RARP for configuring the IP address. Off
Enable DNS Dynamic
Update
Activate this setting to perform DNS server registration automatically. Off
Use Zeroconf Func-
tion
Activate this setting to use Bonjour. On
IP Address Specify the printer's IP address. 0.0.0.0
Subnet Mask Specify the printer's subnet mask. 0.0.0.0
Gateway Address Specify the printer's default gateway. 0.0.0.0
LPD Printing Activate this setting to use LDP Printing. On
IPP Printing Activate this setting to use IPP Printing. On
IPP Printer URI Specify the URI of the printer used for IPP printing using up to 252 charac-
ters.
printer
RAW Printing Activate this setting to use Raw Printing. On
RAW Mode Bi-direc-
tion
Activate this setting to use Raw mode bidirectional communication. Off
FTP Printing Activate this setting to use FTP Printing. On
Use Discovery Activate this setting to use SLP Discovery function. On
Scope Enter the SLP search range. default
SMTP Server Ad-
dress
Specify the SMTP server's IP address.
You can also specify the SMTP server domain name, if desired.
0.0.0.0
Primary DNS Server
Address
Specify the IP address of the primary DNS server. 0.0.0.0
Secondary DNS
Server Address
Specify the IP address of the secondary DNS server. 0.0.0.0
Configuring the Printer's TCP/IP Network Settings With RemoteUI iPF830
User's Guide
Network Setting Initial Settings
484

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
