Canon imagePROGRAF iPF830 User Manual

4 Press ▲ or ▼ to select Output Method, and then press the OK button.
Note
• If a password has been set on the printer, the Logon screen is displayed.
To change the settings, select Administrator and press the OK button. When the Admin.Pswd screen is
displayed, enter the password and press the OK button to proceed to the next step.
If you select User and press the OK button, you can check settings values but cannot change them.
5 Press ▲ or ▼ to select Print, Print (Auto Del), or Save: Box 01.
Follow these steps only when you select Save: Box 01.
6 Press ▲ or ▼ to select the box, and then press the OK button.
Specify Print After Recv
To save print jobs on the hard disk before printing, specify Print After Recv.
Printing will start when Print After Recv is set to On, even if you have selected Save: Box 01 in Output Method.
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Settings/Adj. tab (
).
Note
•
If the Tab Selection screen is not displayed, press the Menu button.
2
Press the
OK button.
The Set./Adj. Menu is displayed.
3 Press ▲ or ▼ to select System Setup, and then press the OK button.
4 Press ▲ or ▼ to select Print After Recv, and then press the OK button.
5 Press ▲ or ▼ to select On or Off, and then press the OK button.
Printing Without Saving Jobs in the Common Box
Printing Without Saving Jobs in the Common Box
Jobs sent from a computer for which you have selected Print in Output Method (in Windows) or Send job to (in
Mac OS) in the printer driver are saved in the shared mailbox. (See "Using the Printer Hard Disk.") ➔P.513
When Common Box Set. is Print (Auto Del) in the Control Panel menu, print jobs for which you have selected
Print in the Output Method dialog box of the printer driver are deleted from the shared mailbox after printing.
Use this function when printing highly confidential documents.
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Settings/Adj. tab ( ).
Note
•
If the Tab Selection screen is not displayed, press the Menu button.
2 Press the OK button.
The Set./Adj. Menu is displayed.
iPF830 Printing Without Saving Jobs in the Common Box
User's Guide
Print Job Management Advanced Print Job Operations
533

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
