Canon imagePROGRAF iPF830 User Manual

5
Enter an administrator name/password and click the Install
Software button.
6
Click the Close button.
The installation of Media Configuration Tool is com-
plete.
Note
•
When the installation is completed properly, the Media Configuration Tool folder is saved in the following
folder.
Applications > Canon Utilities > Media Configuration Tool
Important
• After the installation is finished, update the media information by referring to Updating Media Informa-
tion After Installation ➔P.399 .
Updating Media Information After Installation
Updating Media Information After Installation
If you are running the Media Configuration Tool for the first time after installing it, you need to configure the media
information in the printer control panel and printer driver.
Important
•
You do not need to perform this procedure if you installed the printer driver using the User Software CD-ROM.
• Do not attempt to print or turn the printer off while the program is communicating with the printer.
1 From the Applications menu, select Canon Utilities > imagePROGRAF Media Configuration Tool >
CNWIMCT.
2
The Select Printer dialog box is displayed. Select
the printer for which to configure the media informa-
tion, and then click the Next button.
Note
•
The printers for which the printer driver is installed are displayed. If the printer you want to configure is not
displayed, check whether the printer driver for the target model is correctly installed.
• In the following screens, you cannot change the printer where media type information is to be updated.
iPF830 Updating Media Information After Installation
User's Guide
Handling and Use of Paper Media Configuration Tool (Mac OS)
399

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
