Garmin G300 Pilot’s Guide
190-00921-00 Rev. D
82
GPS Navigation
System
Overview
Flight
InstrumentsEIS
COM
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
Features
Integrated
AutopilotAnnun/AlertsAppendixIndex
MAP PANNING
Map panning allows the pilot to:
•Viewpartsofthemapoutsidethedisplayedrangewithoutadjustingthemap
range
•Highlightandselectlocationsonthemap
•Reviewinformationforaselectedairport,NAVAIDoruserwaypoint
•Designatelocationsforuseinightplanning
•Viewairspaceandairwayinformation
When the panning function is selected by pressing the FMS Joystick (PAN MAP
Softkey on the Weather Page) the Map Pointer flashes on the map display. A
window also appears at the top of the map display showing the latitude/longitude
position of the pointer, the bearing and distance to the pointer from the aircraft’s
present position, the elevation of the land at the position of the pointer, or the
object’s (airports, obstacles, etc) elevation, if known.
When the Map Pointer is placed on a map feature, the map feature is highlighted
and an information box appears (even if the name was not originally displayed
on the map).
Pressing the ENT Key displays a review page for the highlighted map feature.
If multiple features are present at the Map Pointer position, a green arrow will
appear in the information box. Turning the FMS Joystick will cycle through the list
of map features present at that position.
