By default, the Single Display and the Dual Display PFD data bar fields are set
to display Next Waypoint (WPT), Bearing to Waypoint (BRG), Distance to Waypoint
(DST), and Estimated Time Enroute (ETE). The Dual Display MFD data bar fields
default to Ground Speed (GS), Ground Track (TRK), Minimum Safe Altitude (MSA),
and Vertical Speed Required (VSR). These four data fields can be changed to
display any of the Data Bar Field Options. Refer to the Annunciations and Alerts
Section for a list of available Data Bar Field options.
Changing the information shown in the data bar fields:
1) Press the MENU Key twice to display the Main Menu.
2) Turn or move the FMS Joystick to highlight ‘System Setup...’ and press
the ENT Key.
3) With ‘Data Bar Fields’ highlighted, press the ENT Key.
4) Move the FMS Joystick to highlight the desired ‘Field’.
5) Turn the FMS Joystick to access the list of options, then turn or move
the FMS Joystick to highlight the desired option and press the ENT
Key.
6) To restore defaults, press the MENU Key. With ‘Restore Default’
highlighted, press the ENT Key.
DISPLAY
The Backlight Intensity (display brightness) can be set to ‘Auto’(default) or
‘Manual’. ‘Auto’ sets the Backlight Intensity based on the aircraft’s instrument
lighting bus voltage. With ‘Manual’ selected, the pilot can manually adjust the
desired backlight intensity (1-10). The system reverts to the default ‘Auto’ mode
after each power cycle.
Display Setup Page (Single Display)
