The display of radar coverage is always active when NEXRAD is selected. Areas
where NEXRAD radar coverage is not currently available or is not being collected
are indicated in grayish-purple (Weather (WX) Page Only). Radar capability exists
in these areas, but it is not active or is off-line.
neXRAD Ab n o R m A l i t i e S
There are possible abnormalities regarding displayed NEXRAD images. Some,
but not all, of those include:
•Groundclutter
•Strobesandspuriousradardata
•Sunstrobes,whentheradarantennapointsdirectlyatthesun
•Militaryaircraftdeploymetallicdust(chaff)whichcancausealterationsin
radar scans
•Interferencefrombuildingsormountains,whichmaycauseshadows
neXRAD li m itAt i o n S
Certain limitations exist regarding the NEXRAD radar displays. Some, but not
all, are listed for the user’s awareness:
•NEXRADbasereectivitydoesnotprovidesufcientinformationtodetermine
cloud layers or precipitation characteristics (hail vs. rain). For example, it is
not possible to distinguish between wet snow, wet hail, and rain.
•NEXRADbasereectivityissampledattheminimumantennaelevationangle.
An individual NEXRAD site cannot depict high altitude storms at close ranges,
and has no information about storms directly over the site.
•Radarcoverageonlyextendsto55°N.
•Anyprecipitationdisplayedbetween52°Nand55°Nisunknown.
