GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 4-20 Section 4-3 - General Procedure
4-3-11-4 Archiving Images
To export an exam(s) to a compatible Ultrasound system:
1.) Format the removable media (CD-ROM/DVD-R). Label the removable media. Answer Yes/OK
to the messages.Press Patient. Deselect any selected patient(s) in the search portion of the
Patient screen. Press Exam Data Transfer (located at the upper, left-hand corner of the Patient
menu).
2.) Select Export task Button.
3.) The [From] combo box is not active. It displays Local Archive. The [To] combo box is active.
Select the type of removable media CD R/DVD-R. Then please wait until the patient list is
visible.
Figure 4-17 Exam Data Transfer
Figure 4-18 Task button
Figure 4-19 To Combo Box
