GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 7-20 Section 7-1 - Overview
7-7-4 FRU Test
7-7-4-1 SYSCONML
These programs are provided for testing the SYSCONPM/SYSCONCM board.
Table 7-2 FRU Test, SYSCONPM/SYSCONCM Diagnostics Menu
Menu
Descriptions
User
Level
Tools
Full Test
Performs all of the SYSCONML assy tests listed below All None
Assy Revision Test
Test EEPROM.
Send test pattern to write to EEPROM and read
Displays the board revision of the SYSCONML assy
All None
USC I/F Test
The DTRX64II, PI128II, optional CWD64 assay are connected to the SYSCONML via
the FEBUS.
The DSP in SYSCONML accesses the boards above to check if the FEBUS is
connected properly to each assy.
All None
FEBUS Test
Checks if The DSP in SYSCONML accesses the assys, DTRX64II and CWD64, via
the FEBUS.
All None
TRIG Test
Check the trigger max, min and ever interval All None
PCI I/F Test
Sends the command to the DSP to check the SDRAM in SYSCONML All None
DSP Memory Test
Sends the command to the DSP to check the internal DSP memory All None
Board Temperature
Read SYSCONML Assy Temperature. All None
CHACOM I/F Test
Sends the command to read / write data from DSP to CHACOMs All None
To Next Page
