GE LOGIQ P6 Pro Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 4-30 Section 4-7 - Keyboard Function Checks
4-7-6 TGC key assy / TGC Knob Set validation
1.) Follow up the procedure 4-7-1 "Main Keyboard Assy Function Validation Procedure" on page 4-26
to run the scfpapitest program.
2.) Slide TGC pot and check up the value.
4-7-7 Sub Keyboard Encoder Knob Set validation
Follow up 4-7-2 "Sub Keyboard Assy Function Validation Procedure" on page 4-29.
NOTICE
While sliding TGC pot, TGC message should be displayed.
