GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 7-28 Section 7-1 - Overview

7-9-2 System Does Not Boot

Figure 7-14 System does not Boot

System doesn’t boot!

Connect the AC power cable

between the Scanner and the wall

power outlet in right way.

YES

Turn ON the main breaker of

the Scanner.

Go on to the next page.

Is the AC power cable

seated to the Scanner and

to the wall power outlet?

Is the main breaker turned

ON?

Press the ON/OFF button on the

Control Panel.

Has the ON/OFF

key on the Control Panel

been pressed once?

YES
