LOGIQ™ P6/P6 PRO SERVICE MANUAL

Chapter 3 - Page 3-19

3-6-4-1 External I/O Pin Outs

Pin No. Signal Pin No. Signal

1RED9 N/A

2 GREEN 10 SGND

3BLUE11 N/A

4N/A12N/A

5 GND 13 HSYNC

6 RGND 14 VSYNC

7 GGND 15 N/A

8BGND

Table 3-6 Pin Assignments of DB15 connector for External VGA

Pin No. Signal Pin No. Signal

1+5 VDC3DATA +

2 DATA - 4 GND

Table 3-7 Pin Assignments of USB

Pin No. Signal Pin No. Signal

1TX+5 NC

2 TX- 6 RX-

3RX+7 NC

4NC8NC

Table 3-8 Pin Assignments of Ethernet
