GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 5 - Page 5-25
5-7-3 Global Service User Interface (GSUI)
GSUI is the pattern for the user interface. This interface standard will be followed by all modalities to
achieve a common look-and-feel for service software across all GEMS products.
5-7-3-1 Internationalization
The user interface provided by the service platform is designed for GE personnel and as such is in
English only. At this time there is no multi-lingual capability built into the Common Service Interface.
5-7-3-2 Service Login
1)
T
ouch Utility > Service. It will take about 1p seconds for activations
2) make sure t
hat CAPS is OFF
for password entry performed later.
3) The
Service Login window for Service Platform will be shown on the monitor display.
5-7-3-3 Access / Security
The service interface has different access and security user levels. Each user is only granted access to
the tools that are authorized for their use.
NOTE: A Service Dongle is necessary for use by GE Service when performing proprietary level diagnostics.
OnLine Center access to the scanner requires the password and they must have ‘Disruptive’
permission and customer input to run diagnostics.
NOTE: For a GE Field Engineer, the password changes at specific intervals.
All access to the service interface is via the network port.
Every access request, whether successful or not, will be logged into a service access log that is
viewable to authorized users.
Figure 5-24 Login Screen
Table 5-6 Service Login User Levels
User Level Access Authorization
Operator
These service tools are normally used in-house and are protected with a
special scanner configuration that is not allow leave the facility.
Administrator
Use the On Line Center access method provided by iLinq.
External Service
For a external Service other than GE FE.
GE Service
Require a network connection and knowledge of password.
