5-5-1 Input/Output Signals for peripheral
Table 5-4 Input and Output signals for peripherals
Signal Name
Description
Connection from/via/to
Ethernet
Standard TCP/IP Ethernet
SYSCONML -> P6 ARP II -> 7P LAN
Connector
External VGA
VGA signal output for external VGA monitor
SYSCONML -> P6 ARPII -> LG Connector ->
15P DSUB Connector
Foot Switch
Foot Switch is mechanical switch that
connect a signal to ground
Foot Switch connector -> P6 ARP II (USB HUB)
Composite out for DVD Recorder
Compositor video signal output for DVDR
SYSCONML -> P6 ARP II -> BNC Connector
Composite in for DVD Recorder
Compositor input from DVDR
BNC Connector -> P6 ARP II -> SYSCONML
S-VHS out for DVD Recorder
S-VHS output signal for DVDR Recording
SYSCONML -> P6 ARP II -> S-VHS Connector
S-VHS in for DVD Recorder
S-VHS input signal for DVDR playback
S-VHS Connector ->P6 ARP II -> SYSCONML
Audio out L/R for DVD Recorder
Stereo audio output for DVDR Recording
SYSCONML -> P6 ARP II -> RCA Jack
Audio In L/R for DVD Recorder
Stereo audio input from DVDR for DVDR
playback
RCA Jack -> P6 ARP II -> SYSCONML
USB Port for BW Printer
USB Port for BW Printer
SYSCONML -> BP128(Backplane) -> USB
Connector(dual R_A type) -> Front/BW Printer
USB Port for ECG
USB Port for ECG
P6 ARP II (USB HUB) -> USB Connector(R_A
type) -> ECG
USB Port for 4D
USB Port for 4D
P6 ARP II (USB HUB) -> USB Connector(R_B
type) -> 4D
USB Port for Digital Color Printer
USB Port for Color Printer
P6 ARP II (USB HUB) -> USB Connector(S_A
type) -> Color Printer
USB Port for DMC
USB Port for DMC
P6 ARP II (USB HUB) -> USB Connector(S_A
type) -> DMC
USB Port for USB Device
USB Port for USB Device
P6 ARP II (USB HUB) -> USB Connector(S_A
type) -> USB Device
USB Port for Remote
USB Port for remote control of VCR/DVD
Recorder
P6 ARP II (USB HUB) -> USB Connector(S_A
type) -> VCR
