GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 8-106 Section 8-3 - Software Loading Procedure

8-3-5 Before Starting Software Loading

8-3-5-1 Saving Connectivity

Before starting upgrade, write down

the Connectivity Setting for back-up.

1.) Go to Utility > Connectivity and click the TCP/IP tab.

2.) Write down the following parameters:.

Parameters Descriptions (Entry for Stand-Alone System)

Computer Name

Enable DHCP

IP-Address

Subnet Mask

Default Gateway

Note : For a stand-alone system, preset values of IP address, subnet mask, and default gateway, shown

above, must entered.

Figure 8-154 Connectivity
