GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 6-4 Section 6-4 - Trackball Cleaning

Section 6-4

Trackball Cleaning

The trackball on the keyboard need to be cleaning periodically.

1.) Open the trackball.

Figure 6-4 Open Trackball

Figure 6-5 Trackball Hole

Remove dust inside of bucket
