ENGINE
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
1-S10
3. TIGHTENING TORQUES
[1] CABIN MODEL
9Y1211167ENS0003US0
Item N·m kgf·m lbf·ft
Alternator B terminal 5.9 to 9.8 0.6 to 1.0 4.4 to 7.2
Starter B terminal 7.4 to 9.8 0.75 to 1.0 5.5 to 7.2
Seat Bracket mounting bolts and nuts 23.5 to 27.5 2.4 to 2.8 18 to 20
Step mounting bolts 23.5 to 27.5 2.4 to 2.8 18 to 20
Outer roof mounting screw 3.5 to 4.0 0.36 to 0.40 2.6 to 2.9
Cabin mounting bolt and nut 124 to 147 12.6 to 15.0 91.2 to 108
Joint bolt for delivery pipe 2 (Hydraulic pump side) 40 to 49 4.0 to 5.0 29 to 36
Joint bolt for delivery pipe 2 (Valve side) 49 to 68 5.0 to 7.0 37 to 50
Joint bolt for power steering delivery pipe 49 to 68 5.0 to 7.0 37 to 50
Retaining nut for delivery pipe 1 89 to 100 9.0 to 11 65 to 79
Retaining nut for power steering delivery pipe 49 to 58 5.0 to 6.0 37 to 43
Joint bolt for oil cooler pipe 89 to 98 9.0 to 10 65 to 72
Engine and clutch housing mounting screw and nut 78 to 90 7.9 to 9.2 58 to 66
Muffler mounting screw 32 to 37 3.2 to 3.8 24 to 27
Joint screw for power steering delivery pipe 40 to 49 4.0 to 5.0 29 to 36
Retaining nut for power steering delivery pipe 49 to 58 5.0 to 6.0 37 to 43
Front axle frame mounting screw (7T) 78 to 90 7.9 to 9.2 58 to 66
Front axle frame mounting screw (9T) 103 to 117 10.5 to 12.0 76.0 to 86.7
