[6] COLOR OF WIRING
• Colors of wire are specified to the color codes.
• This symbol of "/" shows color with stripe(s).
(An example)
Red stripe on white color: W/R
WSM000001GEG0079US0
Color of wiring Color code
Black B
Brown Br
Green G
Gray Gy or Gr
Blue L
Light Green Lg
Orange Or
Pink P
Purple Pu or V
Red R
Sky Blue Sb
White W
Yellow Y
(1) Wire Color (2) Stripe
