BRAKES
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
5-S2
2. SERVICING SPECIFICATIONS
9Y1211167BRS0002US0
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 15 to 20 mm
0.59 to 0.78 in.
–
Cam Plate Flatness – 0.30 mm
0.012 in.
Cam Plate and Ball Height 20.9 to 21.1 mm
0.823 to 0.830 in.
20.5 mm
0.807 in.
Brake Disc Thickness 4.60 to 4.80 mm
0.181 to 0.188 in.
4.20 mm
0.165 in.
Plate Thickness 2.54 to 2.66 mm
0.100 to 0.104 in.
2.1 mm
0.083 in.
Parking Brake Cable Length 108 to 112 mm
4.25 to 4.41 in.
–
