STEERING
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
7-S3
2. SERVICING SPECIFICATIONS
STEERING CONTROLLER
STEERING CYLINDER
9Y1211167STS0002US0
Item Factory Specification Allowable Limit
Relief Valve
Condition
• Engine Speed:
Maximum
• Oil Temperature:
40 to 60 °C (104 to 140 °F)
Setting Pressure
L3540-II, L4240-II
L5040-II, L5240-II,
L5740-II
10.7 to 11.7 MPa
110 to 119 kgf/cm
2
1560 to 1690 psi
12.7 to 13.7 MPa
130 to 139 kgf/cm
2
1850 to 1980 psi
–
–
Item Factory Specification Allowable Limit
Steering Cylinder I.D. 55.000 to 55.074 mm
2.1654 to 2.1682 in.
55.100 mm
2.1693 in.
Rod to Bushing Clearance 0.009 to 0.127 mm
0.000355 to 0.00500 in.
0.135 mm
0.00531 in.
