INFORMATION
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
I-9
[2] GST MODEL
(To be continued)
Model L5040-II
Engine
Model V2403-M-TE3-EU1
Type Indirect injection vertical, water-cooled, 4-cycle diesel
Number of cylinders 4
Total displacement 2.434 L (148.5 cu.in.)
Bore and stroke 87 × 102.4 mm (3.4 × 4.0 in.)
Net power*
36.0 kW
(48.9 HP)
PTO power*
(factory observe)
32.8 kW
(44.6 HP)* /
2600 min
-1
(rpm)
Maximum torque
162.2 N·m
(16.5 kgf·m, 133.2 lbf·ft)
Battery capacity 12 V, RC: 133 min, CCA: 582 A
Capacities
Fuel tank 54 L (14.3 U.S.gals, 11.9 Imp.gals)
Engine crankcase (with filter) 9.4 L (9.9 U.S.qts, 8.3 Imp.qts)
Engine coolant 8.2 L (8.7 U.S.qts, 7.2 Imp.qts)
Transmission case 46 L (12.2 U.S.gals, 10.1 Imp.gals)
Dimensions
Overall length
(without 3 point hitch)
3245 mm (127.8 in.)
Overall width
(min. tread)
1560 mm (61.4 in.)
Overall height 2375 mm (93.5 in.)
Wheel base 1915 mm (75.4 in.)
Min. ground clearance 405 mm (15.9 in.)
Tread
Front 1135 mm (44.7 in.)
Rear
1225 mm (48.2 in.),
1325 mm (52.2 in.)
To Next Page
