CABIN
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
10-S5
2. SERVICING SPECIFICATIONS
9Y1211167CAS0002US0
Item Factory Specification Allowable Limit
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure Side)
Pressure
(HI Pressure Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
21 to 28 psi
1.27 to 1.66 MPa
13 to 17 kgf/cm
2
185 to 242 psi
–
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure Side)
Setting Pressure
(HI Pressure Side)
Less than
approx.
0.196 MPa
2.0 kgf/cm
2
28.4 psi
More than
approx.
3.14 MPa
32 kgf/cm
2
455 psi
–
–
Air-gap of A/C Compressor Magnet Clutch Air-gap 0.3 to 0.65 mm
0.020 to 0.025 in.
–
Air Conditioner Drive Belt Tension 10 to 12 mm
(0.39 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbf) of force
–
Stator Coil Resistance 3.0 to 4.0 Ω –
KiSC issued 02, 2015 A
