ELECTRICAL SYSTEM
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
9-M18
(2) Attention Display (At Engine Starting)
If neither of the levers or pedals are in neutral positions when the main switch is turned to the "START" position,
the engine cannot be started. The electronic instrument panel displays a message for the operator to correct the
situation by placing the appropriate lever or pedal in the neutral position.
Manual Transmission and GST Model
The safety switch for engine starting is adapted for the shuttle lever and the PTO shift lever in these models.
(Reference)
• As for the manual transmission model, selected speed displayed on left edge is not indicated.
9Y1211167ELM0045US0
When the shuttle lever is not set at a Neutral position
Shift the shuttle lever to Neutral position.
9Y1211167ELM0046US0
When the PTO shift lever is not set at a Neutral
position
Shift the PTO shift lever to Neutral position.
9Y1211167ELM0047US0
When both the shuttle lever and the PTO shift lever
are not set at a Neutral position
Shift both shuttle lever and PTO shift lever to Neutral
position.
9Y1211167ELM0048US0
