CLUTCH
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
2-S4
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1211167CLS0003US0
Item N·m kgf·m lbf·ft
Alternator B terminal 5.9 to 9.8 0.6 to 1.0 4.4 to 7.2
Starter B terminal 7.4 to 9.8 0.75 to 1.0 5.5 to 7.2
Seat bracket mounting bolts and nuts 23.5 to 27.5 2.4 to 2.8 18 to 20
Step mounting bolts 23.5 to 27.5 2.4 to 2.8 18 to 20
Outer roof mounting screw 3.5 to 4.0 0.36 to 0.40 2.6 to 2.9
Cabin mounting bolt and nut 124 to 147 12.6 to 15.0 91.2 to 108
Joint bolt for delivery pipe 2 (Hydraulic pump side) 40 to 49 4.0 to 5.0 29 to 36
Joint bolt for delivery pipe 2 (Valve side) 49 to 68 5.0 to 7.0 37 to 50
Joint bolt for power steering delivery pipe 49 to 68 5.0 to 7.0 37 to 50
Retaining nut for delivery pipe 1 89 to 100 9.0 to 11 65 to 79
Retaining nut for power steering delivery pipe 49 to 58 5.0 to 6.0 37 to 43
Joint bolt for oil cooler pipe 89 to 98 9.0 to 10 65 to 72
Engine and clutch housing mounting screw and nut 78 to 90 7.9 to 9.2 58 to 66
Clutch mounting screws 24 to 27 2.4 to 2.8 18 to 20
Release fork setting screws 24 to 27 2.4 to 2.8 18 to 20
