ELECTRICAL SYSTEM
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
9-S18
[2] ECU AND ELECTRONIC INSTRUMENT PANEL (INTELLIPANEL)
(1) ECU
ECU Connector
1. Remove the seat switch connector.
2. Remover the seat (1).
3. Remove the seat bracket (2).
4. Disconnect the ECU connector (3).
NOTE
• [HST Model]
When replacing the ECU, be sure to adjust the mode "N"
first.
Then adjust the mode "K" and mode "L".
•[GST Model]
When replacing the ECU, be sure to adjust the mode "N"
first.
Then adjust the mode "E" and mode "F".
9Y1211167ELS0012US0
(1) Seat
(2) Seat Bracket
(3) ECU Connector
KiSC issued 02, 2015 A
