Changing the Line Port
61
1
Changing the Line Port
Select a line port or protocol to be used for standard fax or IP-Fax transmission.
When the extra G3 interface unit is installed, you can connect to a maximum of
three ports.
Important
❒ To add more fax lines, the optional extra G3 interface unit is required.
❖ G3
G3 is selected after power up or when the machine is reset. If you install the
extra G3 interface unit, you can select “G3-1”, “G3-2”, “G3-3”, or “G3 Au-
to”depending on the number of the installed unit.
❖ Multi-port
When the extra G3 interface unit is installed, communications can take place
simultaneously through three lines at once.
The following list shows protocol combinations available for each line type.
❖ IP-Fax
When sending an IP-Fax, select either “SIP” or “H.323” as the protocol.
To display “SIP” and “H.323” on the screen, make the settings in “Initial Set-
tings” in the Facsimile Features menu.
Ask your administrator whether you should select “SIP” or “H.323” as the
protocol.
Option Available line types Available protocol combinations
Without option PSTN G3
Extra G3 interface unit PSTN n PSTN G3 n G3
Extra G3 interface unit n
Extra G3 interface unit
PSTN n PSTN n PSTN G3 n G3 n G3
To Next Page
