Bus setups Select the USB serial bus speed

Select the USB serial bus speed

NOTE. USB serial bus Speed selection is available only on instruments with option SR-USB.

From the Bus Setup window, select Serial from the Bus Type list and then select the USB Serial bus type.

To use

To change the speed for the displayed component of the bus, click Speed and select from the cascading list.

Behavior

The instrument acquires data from the channel you select for each component.

What do you want to do next?

Learn

more about bus setups.

(see page 95)

Learn about bus conﬁguration. (see page 148)

Learn about digital setups. (see page 87)
