Analyzing waveforms Set up Parallel search parameters
Learn about bus setups (see page 95)..
Learn about Custom Serial Bus Setup (see page 112)
Set up Parallel search parameters
After setting up a parallel bus, go to the Analyze menu, select Search, and then select the Bus trigger type;
then open the Configure tab.
Overview
Use the controls to set up the Parallel Bus parameters.
To use
For information o n the controls, click the buttons.
Behavior
Clicking an entry in the Type column activates the individual search controls, similar to the one shown
above. These controls vary depending on the search Type. Setting the search conditions is similar to
setting the parameters for an Event Trigger
(see page 386).
NOTE. No information will be displayed in this window until you specify at least one search Type in
the Search Select Control Window
(see page 300).
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 369
