Tektronix DPO70000C/DX Series User Manual

Trigger setups Set up a CAN bus trigger
Trigger on Error
The error type o ptions available in Trigger on Error are as follows:
Set up a CAN bus trigger
NOTE. The Bus Trigger Control Window for CAN Serial option is available only on instruments with
option SR-AUTO.
From the Trigger menu, select Bus setup.
Overview
Use the controls to set up the CAN Bus parameters.
To use
For information o n the controls, click the buttons.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 407
